The Hummerbee 525R Compact Loader combines power, precision, and efficiency in one compact, easy-to-maneuver machine. Designed to excel in tight spaces and tough conditions, the 525 Loader is an ideal choice for industries that require reliable equipment in challenging environments, from construction sites to agricultural applications.
Compatible with All Universal Skid Steer Attachments
The Hummerbee 525R Compact Loader combines power, precision, and efficiency in one compact, easy-to-maneuver machine. Designed to excel in tight spaces and tough conditions, the 525R Loader is an ideal choice for industries that require reliable equipment in challenging environments, from construction sites to agricultural applications.
| Engine: | Kubota V1505 Diesel, 1.5L 4-Cylinder, Tier 4 |
|---|---|
| Horsepower: | 24.8 HP @ 2,600RPM |
| Torque: | 68.3 Ft-Lbs @ 1,700 RPM |
| 4WD Transmission: | 2-Speed |
| Maximum Speed: | 12 MPH/High; 5 MPH Low |
| Standard Tires: | 26×12.50×12; Ag/Pneumatic |
| Maximum Lift Height: | 102″ (to Hinge) |
| Maximum Lift Capacity: | 2,000 lbs.: 2,700 lbs. w/Cntrwts. |
| Aux. Hydraulics Flow: | 14 GPH |
| Total Weight: | 4,570 lbs. w/Ag Tires; Pneumatic |
| Overall Height: | 89.5″ (Approx.) |
| Overall Length: | 113″ w/o Bucket |
| Overall Width: | 55” w/Standard Tires |
| Fuel Capacity: | 15 gal Tank |
| Hydraulic Oil Capacity: | 15 gal Tank |
| Turning Radius: | 42 Inches |
| Frame Oscillation: | +/-8 Degrees |
| Wheel Base: | 53″ |
| Ground Clearance: | 7″ from Ground to Transfer Case |
