Hummerbee XRT

High Capacity, Super Strength, Ultra Power

The Hummerbee XRT Forklift is the latest machine in the evolution of the Hummerbee forklift lineup. When it comes to material handling, the XRT is unsurpassed in its class. It’s smoother, faster, stronger, and more robust than any machine that has come before it. More Power, new articulated joint design, improved transfer case, upgraded joystick controls, and a greater lift capacity are just a few of the advancements that make this the ultimate rough terrain forklift. Evolved from a 35-year heritage, the XRT was born to rule the roughest terrain!

Kubota KDI 2504TCR | 74HP | 4-CYL | TIER 4

  • Max. Lift Capacity – 4,000 lbs.
  • Max. Mast Height – 126″ Standard; 144″ Optional
  • Base Weight – 6,300 lbs.
  • Aux. Hydraulic Flow – 16 GPM

Give Us A Call Today!

Hummerbee XRT Forklift Right Side View
Hummerbee XRT

Product Description

Unstoppable Power at your Command

The Hummerbee XRT is the heavyweight champ of rough terrain forklifts. It’s a virtual pack mule for your apiary, orchard, farm or construction site — but much quicker on it’s feet. The 74HP Kohler turbo diesel is the biggest and baddest engine in it’s class. But the XRT doesn’t just rely on the engine to flex its muscle.

The 21 GPM combined hydraulics flow readily commands the heavy-duty mast or any other auxiliary tools you can match it up
with. And, the 4WD, 2-speed hydrostatic transmission with on-the-fly shifting, eagerly propels the XRT through the most challenging terrain.

And, to be sure the XRT keeps on hauling all day long, its Tier 4 Final, turbo-charged power plant is armed with an intercooler to reduce NOx emissions, boost power, and lower engine temperature for peak performance, and longer engine life.

Strength and Stability when you Need It

High-grade, US steel body panels, best-in-class lift capacity, and a robust, 6,300 lb. weight package, makes the XRT virtually indestructible. But don’t let its size fool you! Equipped with an articulating center joint, an oscillating trunnion-drive rear axle, and our exclusive load cushion technology, the XRT is stable enough to safely and effortlessly navigate any terrain.

Technology at your Fingertips

The intuitive, multi-function joystick controller and electronic control switches allow for intuitive, on-demand tool and load adjustments. Our exclusive, easy-to-read digital ECU display is programmed to provide accurate, real-time engine statistics, along with a configurable scale gauge.

Rounding out the control console is an integrated engine systems diagnostics port. Quickly diagnose any fault codes thrown at you for faster troubleshooting and maintenance. And, if an ECM upgrade is required or released by the engine manufacturer, Hummerbee will provide the file to be uploaded directly into the ECU via the diagnostics port.

Peace of Mind

We’re so confident in the quality and durability of the Hummerbee XRT, we back it up with a 2-Year, Parts & Labor Warranty.

Features

  • Tier 4 Final Kohler-KOI 2504TCR 4-Cycle Engine
  • Multi-function joystick controller and electronic control switches
  • 4 Wheel Drive
  • 2 Speed, Dynamic Drive Shaft On-The-Fly Transmission
  • 21 GPM combined hydraulics flow provides auxilliary attachment operation

Shown in Standard Orange Color Option

  • Standard Color: Yellow, Green, White, Orange, Red
  • Optional: Custom Paint Matching Available

Specifications

Engine: Kohler-KDI 2504TCR, 4-Cylinder, Tier 4 Final
Horsepower: 74 HP @ 2,600 RPM, Turbo Charged
Torque: 221 Ft-Lbs @ 1,500 RPM
Transmission: 4WD; 2-Speed Hydrostatic
Maximum Speed: 12 MPH/High; 6 MPH Low
Fuel Capacity: 12 gal Tank
Hydraulic Oil Capacity: 12 gal Tank (10 gal max fill level)
Hydraulic Steering: 5 GPM
Aux. Hydraulics Flow: 16 GPH
Total Weight: 6,300 lbs. w/Liquid Filled Tires
Fork Length: 42″ Standard; 48″ Optional
Overall Length: 108.3″ w/o Forks; 151.8″ w/42″ Forks
Overall Width: 55.4” w/Standard Tires
Overall Height: 94″; 104″ w/Optional 144″ Mast
Maximum Mast Height: 126″ Standard; 144″ Optional
Maximum Lift Capacity: 3,000 lbs.: 4,000 lbs. w/Counterweights
Mast Side Shift: 6″
Mast Tilt: 16 Degrees
Max. Articulation Angle: 33 Degrees
Frame Oscillation: +/-8 Degrees
Standard Tires: 29×12.50×15; Liuid Filled; Ag
Wheel Base: 49″
Ground Clearance: 9″ from Ground to Transfer Case
Standard Colors: Yellow, Green, White, Orange, Red

Forklift Attachments

Maximize the functionality of your Hummerbee forklift with a range of versatile attachments designed for diverse applications. From orchards to warehouses, these tools allow you to tackle tasks efficiently and effectively.

  • Forks: Ideal for standard material handling, including pallets, crates, and beehives, ensuring smooth and secure transport.
  • Load Clamp: Perfect for apiary operations and orchards, the load clamp securely grips and moves beehives or boxes of crops with precision.
  • Drum Grabber: Safely lift and transport large drums, making it an excellent tool for agricultural, industrial, or warehouse use.
  • Brush Mower: Easily clear overgrown vegetation and brush, ideal for maintaining orchards, fields, and site perimeters.
  • Snow Blade: Keep your operations running through winter by efficiently pushing and clearing snow from work areas and pathways.
  • Custom Attachments: Need a specialized tool for your operation? Hummerbee offers custom attachment solutions to meet your needs.

Upgrade your Hummerbee forklift with attachments built to handle the toughest jobs. Contact us today to explore your options or inquire about custom attachment solutions!
